Description
1. Product Introduction
The emergency stop push button is designed and manufactured to operate under extreme conditions. These switches have compact, sealed, solid enclosures and high impact, vibration, dust and moisture resistance
2.Product Parameter (Specification)
| Rated insulation voltage | AC 600V (50/60Hz) | |
| Convectional current | 10A | |
| Insulation resistance | ≥50MΩ | |
| Contact resistance | ≤25MinΩ | |
| Mechanical life | 100*104(Pushbutton) | 50*104(Selector switch/Key switches) |
| Electrical life | 500*104(Pushbutton) | 250*104(Selector switch/Key switches) |
1.Surrounding temperature : -25℃~+55℃;
2.Air relative humidity : ≤85%;
3.It can be normally work under following condition : Vibration frequency is 2-80Hz and acceleration speed is 0.7g/h;
4.Pollution grade III,installation sort is III, protection grade is up to IP65;
5.Altitude : ≤2000m.
3.Product features and applications
When machines and systems are in danger, they must be shut down immediately to protect personnel, machines and systems.
The emergency stop push button is an ideal solution for starting and stopping.. It is a button with a very strong metal body. Press the red key to block the switch. Unlocking is accomplished by turning the red mushroom.
4. Product Details
Compact, sealed, rugged housing
High resistance to shock, vibration, dust and moisture
The emergency stop push button body is made of alloy and plastic.
